Specification1) Conductor resistance:a) 0.1 x 1.27 (T x W):b) 0.1 x 0.8 (T x W):c) 0.1 x 0.6 (T x W):d) 0.1 x 0.5 (T x W):e) 0.1 x 0.3 (T x W):f) 0.05 x 1.27 (T x W):g) 0.05 x 0.8 (T x W):h) 0.05 x 0.6 (T x W):i) 0.05 x 0.5 (T x W):j) 0.05 x 0.3 (T x W):k) 0.035 x 1.27 (T x W):l) 0.035 x 0.8 (T x W):m) 0.035 x 0.6 (T x W):n) 0.035 x 0.5 (T x W):o) 0.035 x 0.3 (T x W):2) Insulation resistance: >50 omega/m3) Dielectric strength: no breakdown, AC 500V for 1 min4) Open /short test: pass, DC 3.0V 0.1mA5) Heat resistance: insulation resistance and dielectric strength pass6) Heat cycle test: insulation resistance and dielectric strength pass,-40-25-85-25C for 5 cycles7) Moisture resistance: insulation resistance and dielectric strength pass, 40C,95% RH for 96h8) Flame test: pass UL VW-19) Flexing test: >3,000,000 cycles, 10R/10cm at 70 cycles/min10 Bending test (180 degree): (clip the point of supporting tape)100 cycles-90to 90/600g/0.5R11) Abrasion test: >10,000 cycles, 5R/600g, 60 cycles/min
Product Name: FFC CablePlace of Origin: ChinaSpecification1) Conductor resistance:a) 0.1 x 1.27 (T x W):b) 0.1 x 0.8 (T x W):c) 0.1 x 0.6 (T x W):d) 0.1 x 0.5 (T x W):e) 0.1 x 0.3 (T x W):f) 0.05 x 1.
