PTYA23 (22) Railway Signal Cable
Product Name: PTYA23 (22) Railway Signal CablePlace of Origin: ChinaType: PTYA23 (22)Size: 4-61 coresExecutive Standard: TB/T 2476. 1~4-93Referred Standard: IEC, ASTM, BSFeatures:1) Structure: Quad-twisted pairs or insulated wires twisted togetherto form the cable core, cable core wrapped by polyester tape, atow-side plastic coated aluminum tape (PAP) longitudinally appliedas shielding layer, inner sheath. Tow-side plastic coated steel tape(PSP) applied as armoring layer, PE outer sheath2) Installation temperature: Not lower than -5oC3) Operation temperature: Operation environmental temperature: -30oC~+60oC4) Long term operation temperature: ≤70oC5) Min. bending radius: Not less than 10 times of cable outer diameterfor Un-armored cable, and not less than 15 times of cable outerdiameter for armored cable6) Usage: The standard cable is used for transmitting railway singles,audio frequency signals with fixed value of AC 500V or DC 1000V. Orapplied as fixed lay of some auto mechanism7) Application mode: direct buried, conduitInner packing: Delivery on wooden-iron composite drums, strong enoughsuitable for handling, long distance shipment and storageOuter packing: Wooden battens to be used to protect the drummed cableor even a metal tape secured outside
Structure: Optical fiber contained and jelly filled loose tubesor fillers stranded around the non metallic central strengthmember (FRP), water blocking compound material filled in the intersticeof the
Product Name: ADSS Optical Fiber CableModel Number: ADSSPlace of Origin: ChinaStructure: Optical fiber contained and jelly filled loose tubes or fillers stranded around the non metallic central streng
Structure: Fiber contained and jelly filled loose tubesand / or fillers stranded around the non metallic central strengthmember (FRP), water blocking compound material filled in the intersticeof the c
