Product Name: Rotating Horizontal Band Saw MachineModel Number: GB4028 (rotating)Place of Origin: ChinaTechnical data:1) Max. process dimensions: 90 degrees, Φ280mm, 250 x 230mm; 45 degrees, Φ160mm, 160 x 240mm2) Process speed (m/min): 18, 40, 70 (3 steps)3) Band saw: 3,350 x 27 x 0.9mm, 3,350 x 34 x 1.1mm4) Main motor: 1.8kW5) Oil pump motor: 1.1kW6) Rotating degree: 0 - 45 degrees7) Machine weight: 850kgOuter packing:Carton dimensions: 2,000 x 1,100 x 1,200mmWe can provide you with various specifications.
Technical parameters:1) Max. process dimensions: 90° Φ350mm, 230 x 230mm, 45°Φ280mm, 160 x 280mm2) Process speed (m/min): 18, 40, 70, class (3)3) Band saw dimensions: 3,350 x 27 x 0.9m
Technical parameters:1) Max. process dimensions: 150 x 330 x 500mm2) Process speed (m/min): 18, 40, 70 class (3)3) Band saw dimensions: 2,950 x 27 x 0.9mm4) Main motor output: 1.8kW5) Oil pump motor o
Technical parameters:1) Max. process dimensions: 400 x 650 x 2,500mm2) Process speed (m/min): 21, 45, 65 class (3)3) Band saw dimensions: 5,530 x 41 x 1.3mm4) Main motor output: 0.75kW5) Oil pump moto
Technical parameters:1) Max. process dimensions: 600 x 600mm2) Process speed (m/min): 26, 41, 66 class (3)3) Band saw dimensions: 6,900 x 54 x 1.60mm4) Main motor output: 7.5kW5) Oil pump motor output
Features:1) Max. process dimensions: Φ280mm, 800 x 800mm2) Process speed: 18 - 110m/min (belt speeding)3) Band saw: 8,880 x 67 x 1.6mm4) Main motor: 7.5kW, 11kW5) Oil-pump motor: 2.2kW6) Machine
