FM / TV Tuner
Features:1) Working voltage: 10V - 15V2) Working current: 180 - 220mA3) Power consumption: 2.5W4) Audio system: D/K, I, B/G, M (full automatic)5) TV system: PAL (50Hz), NTSC (60Hz), SECAM6) The speed of searching TV station:a) Quickly search: 8 secondsb) Slowly search: 16 seconds7) Antenna input: 75ohms, imbalance8) Video input impedance: 75ohms9) Video output impedance: 75 ohms10) Frequency response: +2.5dB (2-20kHz)11) Dynamic range: ≥70dB (1kHz)12) Harmonic distortion and noise: &le6dB (1kHz)13) AV input function: one-way outside video input, two-way outside audio input(one set of RCA input)14) Audio FM transmit function: the TV-BOX can transmit the inside TV audio and theoutside audio input to TV or AV audio signal through the inside FM emitter15) FM emitter transmit frequency: 88.3MHz and 88.9MHz can be preset16) Receiving channels:a) China channelsi) VHF-L (DS1-DS5, 48.5 MHz-92 MHz) (Z1-Z7, 111.0 MHz-167 MHz)ii) VHF-H (DS6-DS12, 167.0MHz-223.0MHz) (Z8-Z38, 223.0MHz-471.0MHz)iii) UHF (DS13-DS68 470.0MHz-958MHz)b) C.C.I.R channelsc) US channelsd) OIRT channels
