Description
ATV Specifications:1) Engine type: single cylinder, water-cooled, 4-stroke2) Power: 10.3kW/7,500rpm3) Max. torque: 15N.m/6,000rpm4) Min. ground clearance: 120mm5) Wheel base: 1,150mm6) Fuel tank capacity: 4L7) Transmission mode: chain8) Start mode: electric9) Tires:a) Front wheels: 21 x 7-10b) Rear wheels: 20 x 10-1010) Max. speed: ≥75km/h11) Break type (F/R): drum / disc12) Power source: 12V, 9Ah13) Height of seats: 880mm14) Dry weight: 155kg15) Load capacity: 105kg16) Climbing degree: ≥20°17) Front hanging: integral ballonet absorber18) Rear hanging: inner ballonet absorber19) Cylinder size: 63.5 x 62.2mm20) Displacement: 197ml21) Transmission: 4 gears with one reverse gear, manual clutch22) Min. turning radius: 2,650mm23) Parking trig: mechanical lock24) Ignition mode: CDI25) Engine oil: 1.1L26) Max. number of riders: 127) Lubrication: press splash28) Compression proportion: 9.2: 129) Gas cylinder number: 130) Product dimensions (L x W x H): 1,800 x 1,120 x 1,130mmOuter packing:Carton dimensions: 1,470 x 860 x 880mmConveyance:Qty/20` FCL: 20 unitsQty/40` FCL: 44 unitsQty/40` HQ: 66 units Add to Basket
Web address
Other goods of this manufacturer :
ATV
Specifications:1) Engine type: single cylinder, air-cooled, 4-stroke2) Power: 9.9kW/6,500rpm3) Max. torque: 14.9N.m/5,500rpm4) Min. ground clearance: 155mm5) Wheelbase: 1,175mm6) Fuel tank capacity: 1
ATV
Specifications:1) Engine type: single cylinder, water-cooled, four-stroke2) Power: 10.5kW/7,500rpm3) Max. torque: 15N.m/5,500rpm4) Min. ground clearance: 155mm5) Wheel base: 1,160mm6) Fuel tank capaci
ATV
Specifications:1) Engine type: single-cylinder, compelled air-cooled, 4-stroke2) Power: 5.2kW / 7,500rpm3) Max. torque: 8.5N.m / 6,000rpm4) Min. ground clearance: 150mm5) Wheel base: 1,100mm6) Fuel ta
ATV
Specifications:1) Engine type: single cylinder, air-cooled, 4-stroke2) Power: 14.7kW/8,000rpm3) Max. torque: 20N.m/6,000rpm4) Min. ground clearance: 120mm5) Wheel base: 1,220mm6) Fuel tank capacity: 1
ATV
Specifications:1) Engine type: double cylinders, air-cooling, 4-stroke2) Power: 12kW/8,500rpm3) Max. torque: 15N.m/7,000rpm4) Min. ground clearance: 135mm5) Wheel base: 1,180mm6) Fuel tank capacity: 8
ATV
Features:1) Dimensions (L x W x H): 1,620 x 920 x 950mm2) Wheel base: 1,090mm3) Engine type: single cylinder,compelled air-cooling,four stroke4) Start mode: electric/electric kick5) Power: 5.2kW/7,500
ATV
Specifications:1) Engine type: single-cylinder, oil-cooled, 4-stroke2) Power: 6.0kW/7,500rpm3) Max. torque: 7.6N.m/6,500rpm4) Min. ground clearance: 110mm5) Axil base: 1,040mm6) Wheel base: 920/860mm7
ATV
Specifications:1) Engine type: single cylinder, air-cooled, 4-stroke2) Power: 16KW/6,500rpm3) Max. torque: 26N.m/5000rpm4) Min. ground clearance: 260mm5) Wheel base: 1,240mm6) Fuel tank capacity: 14L7
ATV
Specifications:1) Engine type: single cylinder, air cooling, 4-stroke2) Power: 10kW/7,500rpm3) Max. torque: 13.5N.m/6,000rpm4) Min. ground clearance: 140mm5) Wheel base: 1,000mm6) Fuel tank capacity:
