Description |
 |
|
|
|
|
|
|
|
|
|
ATV
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 2.2kW/7,500rpm3) Max. torque: 3.0N.m/6,000rpm4) Min. ground clearance: 95mm5) Wheel base: 700mm6) Fuel tank capacity: 2.75L7) Transmission mode: chain8) Start mode: electric9) Tires:a) Front wheels: 145 / 70-6b) Rear wheels: 145 / 70-610) Max. speed: ≥30km/h11) Break type (F / R): rear disc12) Power source: 12V, 6.5Ah13) Height of seats: 540mm14) Dry weight: 68kg15) Load capacity: 50kg16) Climbing degree: ≥15°17) Front hanging: arm-swing18) Rear hanging: integral19) Cylinder size: 39 x 41.4mm20) Displacement: 49.456mL21) Transmission: 4 gears, automatic clutch22) Min. turning radius: 1,600mm23) Ignition mode: CDI24) Engine oil: 0.8L25) Max. number of riders: 126) Lubrication: press splash27) Compression proportion: 8.8:128) Gas cylinder number: 129) Product dimensions (L x W x H): 1,080 x 670 x 770mmOuter packing:Carton dimensions: 1,120 x 670 x 670mmConveyance:Qty/20` GP: 51 unitsQty/40` GP: 105 unitsQty/40` HQ: 138 units
 Add to Basket
 Web address
|
|
|
Other goods of this manufacturer : |
|
|
|
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 10.0kW/7,500rpm3) Max. torque:13.5N.m/6,500rpm4) Min. ground clearance: 140mm5) Wheel base: 1,000mm6) Fuel tank capacity:
|
| |
|
ATV
|
|
Specifications:1) Engine type: single cylinder, compelled air-cooling, four stroke2) Power: 5.2kW/7,500rpm3) Max. torque: 8.5N.m/6,000rpm4) Min. ground clearance: 110mm5) Wheel base: 1,050mm6) Fuel ta
|
| |
|
ATV
|
|
Specifications:1) Engine type: double cylinder, air-cooling, four-stroke2) Power: 12kW/7,500rpm3) Max. torque: 15N.m/6,500rpm4) Min. ground clearance: 135mm5) Wheel base: 1,180mm6) Fuel tank capacity:
|
|
|
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooled, 4-stroke2) Power: 2.2kW/7,500rpm3) Max. torque: 3.0N.m/6,000rpm4) Min. ground clearance: 95mm5) Wheel base: 700mm6) Fuel tank capacity: 2.75
|
| |
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 3.8kW / 7,500rpm3) Max. torque: 5.5Nm / 5,500rpm4) Min. ground clearance: 100mm5) Wheel base: 890mm6) Fuel tank capacity:
|
| |
|
ATV
|
|
Specifications:1) Engine type: engine type: single cylinder, air-cooled, 4-stroke2) Power: 4.6kW/7,500rpm, max. torque: 6.5N.m/6,000rpm4) Min. ground clearance: 100mm5) Wheel base: 1,070mm6) Fuel tank
|
|
|
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 4.6kW/7,500rpm3) Max. torque: 6.5N.m/6,500rpm4) Min. ground clearance: 100mm5) Wheel base: 1, 030mm6) Fuel tank capacity:
|
| |
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 11kW/7,500rpm3) Max. torque: 17N.m / 6,000rpm4) Min. ground clearance: 140mm5) Wheel base: 1,130mm6) Fuel tank capacity:
|
| |
|
ATV
|
|
Specifications:1) Engine type: single cylinder, air-cooling, 4-stroke2) Power: 2.2kW/7, 500rpm3) Max. torque: 3.0N.m/6,000rpm4) Min. ground clearance: 90mm5) Wheel base: 640mm6) Fuel tank capacity: 3.
|
|
|
|
