HYA Communication Cables (HYA Кабели связи)

Zoom in

Producer information

Company:
Hong'an Group Co., Ltd.

Address:
88 Hengshan Road, Wendeng, Shandong, China (Mainland) Zip: 264400

Phone:
+86-631-8088610 +8088621

HYA Communication Cables

Specifications:1) Type: HYA2) Size: 10 - 2,400 pairs3) Executive standard: YD/T 322-19964) Referred standard: ISO9001Features:1) Structure: annealed copper conductor, solid polyolefin insulation,polyester coated aluminum tape (PAP) longitudinallywrapped, PE sheathed local communication cable2) Installation temperature: not lower than -5°C3) Operation temperature: -30°C - +60°C4) Minimum bending radius: not less than 15 times the outerdiameter when the outer diameter is 40mm or less and notless than 20 times the outer diameter when the outer diameterlarger than 40mm5) Usage: transmitting audio frequency signals, analog signals up to150kHz or digital signals up to 2,048kbps6) Application mode: aerialInner packing:Wooden-iron composite drums, strong enough for handling, long distance shipment and storageOuter packing:Wooden battens used to protect the drummed cable or metal tape secured outside

Add to Basket

Web address

Other goods of this manufacturer :

HYA Communication Cables
	Product Name: HYA Communication CablesModel Number: HYAPlace of Origin: ChinaSpecifications:1) Type: HYA2) Size: 10 - 2,400 pairs3) Executive standard: YD/T 322-19964) Referred standard: ISO9001Featur

HYAC Communication Cable
	Structure: annealed copper conductor, solid polyolefin insulation, jelly filled, polyester coated aluminum tape (PAP) longitudinally wrapped, PE sheathed local communication cable

HYAT Communication Cable
	Structure: annealed copper conductor, solid polyolefin insulation, jelly filled, polyester coated aluminum tape (PAP) longitudinally wrapped, PE sheathed local communication cableInner packing:Deliver

HYAT Communication Cable
	Structure: annealed copper conductor, solid polyolefin insulation, jelly filled, polyester coated aluminum tape (PAP) longitudinally wrapped, PE sheathed local communication cableInner packing:Deliver

Lan Cable
	Pairs ColorWhite/BlueWhite/OrangeWhite/GreenWhite/BrownMaterial InstructionConductor:CopperInsulation:Solid HDPE/Skin-Foam-Skin PE Sheath:PVC/PE/LSNHPPacking1000feet (305m) Per box Over 25pair: 500m~1

LAN Cable
	Specifications:1) Resistance (max): 9.50Ω/100m at 20°C2) D.C. resistance unbalanced (max): 2.5%3) Mutual capacitance (max): 5.6 nF/100m4) Capacitance unbalanced (max): 330Pf/100m5) Materials:

LAN Cable
	Product Name: LAN CableModel Number: HSYVP6-4Place of Origin: ChinaSpecifications:1) Resistance (max): 9.50Ω/100m at 20°C2) D.C. resistance unbalanced (max): 2.5%3) Mutual capacitance (max):

Lan Cables
	Features:1) Pair Color: white/blue, white/orange, white/green, white/brown2) Material instruction:a) Conductor: copperb) Insulation: solid HDPE/skin-foam-skin PEc) Sheath: PVC/PE/LSNHP3) Accordance wi

Lan Cables
	Features:1) Pair Color: white/blue, white/orange, white/green, white/brown2) Material instruction:a) Conductor: copperb) Insulation: solid HDPE/skin-foam-skin PEc) Sheath: PVC/PE/LSNHP3) Accordance wi
