Technical Date of Fiberglass Duct Rodder Specification Rod Diameter (mm) Φ 4.5-Φ 16 Rod Length (m) 30m~500m Frame Spec. (mm) 1300x450x1330,1200x420x1220,980x350x1000,680x240x700, 420x180x400,etc. Material: Fiber glass rod inner, Extruded by fiber glass and high strength resin at high temperature Fiber glass rod outer, High Density polyethylene coating Metal Frame: Steel with high-temperature sprayed plastic or hot dip galvanized Physical Property Fiber glass content:75-80% Density > 1.9gr/cm3 Working environment-40° C to +80° C Minimum Pulling strength 4000N +/-5% Consistency of rod 137gr/m Flexural Modulus > 46.500Mpa Elongation at break 2.5-3% Min Bending Radius 388mm
Fiberglass duct rodder features 1.Light weight,durable,resistance to acid,alkali,aging resistant,corrosion resistant. 2.High tensile strength and bending properties to make it go through narrow pip
The Reel Rod has a sturdy, powder coated, steel tube frame and features a 16" diameter storage basket. Up to 400 ft. of rod can be stored in this basket. A light adjustable brake prevents the rod
Duct rodder/ Cobra Conduit Rod is composed of fiberglass rod which is extruded by fiber glass rod and high strength resin at high temperature.This type of rod has high tensile strength and fle
Fiberglass duct rodder features 1.Light weight,durable,resistance to acid,alkali,aging resistant,corrosion resistant. 2.High tensile strength and bending properties to make it go through narrow pip
High Density polyethylene (Grade: for the insulating and jacketing of Telecommunication Cables) is used in the outer diameter coating.Duct Rodders will equipped with different size reel according to t
Fiberglass duct rodder features 1.Light weight,durable,resistance to acid,alkali,aging resistant,corrosion resistant. 2.High tensile strength and bending properties to make it go through narrow pip
High Density polyethylene (Grade: for the insulating and jacketing of Telecommunication Cables) is used in the outer diameter coating.Duct Rodders will equipped with different size reel according to t
Fiberglass duct rodder is an auxiliary tool applied in towing lead-rope through a pipe. The rod surface is hard and smooth, so it can get through the narrow pipe or channel easily.The inner core of th
