6-35KV Rubber CV Line

6-35KV Rubber CV Line Specification Application The machine is used for making 6-35KV rubber cables by continuous curing process and extruding the single core, multi core and double-layer cable in one time then continuous curing. Main technical data Conductor type: Cat-2 (stranded conductor), Cat-5 (soft conductor), Cat-6 (soft conductor) copper conductor. Conductor cross section: Cu.35-630mm2 Al.50-800 mm2 Extruding material: EPR, CPE, CSPE Curing process method: steam heating, water cooling. Layout type: semi catenary, straight tube type. The total length: 102m Curing tube length: 60m (6m*10) Cooling tube length; 42m (6m*7) The first 6 section is catenary suspension type, the others are tilting type. The exact angle is confirmed by layout. Area of main building platform （L×W）≥24 m×18 m, The height of third floor 　 10 m, Length of workshop 　 ≥130 m Max. line speed 50m/min Steam pressure 25bar Steam using pressure 16bar Steam consumption 28Kg/min(for an instant), 3.5Kg/min(normal using) Water quality: clay granule
