Description
Producer information
Company:CZIC GROUP-PUMP PARTS
Address:JINDING BUILDING 915ROOM,CANGZHOU CITY,HEBEI PROVINCE,CHINA
Phone:+86-317-5671501
Putzmeister Concrete Pump Rubber Hose CZIC GROUP Quick Details
Place of Origin: Hebei, China (Mainland)
Brand Name: Putzmeister
Model Number: DN125
Brand: Putzmeister
Model: 1INCH-6INCH
Material: Forged
1.Export Goods: Pipe,Elbow,Rubber Hose,Clamp,Wear Plate
2.Export Goods: Flange,Rubber Gasket,Piston Ram.Cleaning Ball
Export Country:American,Saudia,Pakistan,Jordan,Qatar,Chile,Russian,Iran etc
Packaging & Delivery
Packaging Details:
According Clients's Required
Delivery Detail:
7DAYS
Specifications
Concrete Pump Rubber Hose
1.Length 1m-10m
2. 4 Steel wires and Fabric
3.Model:DN125
There are two kinds of rubber hoses, steel hoses and fabric hoses, available in size 2" to 5", installed in concrete pumps and shotcrete pumps respectively.
Fabric hose size: 2"-5" Working pressure: 55bar
Wire braid hose size: 2"-5" Working pressure: 85bar
Steel hose
Spec.
Inner diameter (mm)
Wall thickness tolerance (mm)
Outer diameter (mm)
Working pressure (bar)
Bursting pressure(bar)
Bend radius (mm)
Weight(kg/m)
2"
50
90.75
681.5
85
240
200
2.6
2.5"
64
100.75
851.5
85
240
250
4.3
3"
76.2
12.91
1021.5
85
240
270
6.1
3.5"
89
13.51
1161.5
85
240
290
8
4"
101.6
14.21
1301.75
85
240
300
9
4.5"
115
141
1432
85
240
320
10.2
5"
127
161
1582
85
240
360
12.5
Fabric hose
Spec.
Inner diameter (mm)
Wall thickness tolerance (mm)
Outer diameter (mm)
Working pressure (bar)
Bursting pressure(bar)
Bend radius (mm)
Weight(kg/m)
2"
510.7
11.50.7
741
55
220
200
2.80.2
2.5"
63.50.8
120.7
881
55
220
250
3.70.3
3"
761
141
1041.2
55
220
270
4.90.4
3.5"
891
151
1191.2
55
220
290
5.80.4
4"
1021
16
1351.2
55
220
300
7.40.4
4.5"
114
161
1481.5
55
220
320
8.50.5
5"
1271
161
1591.5
55
220
360
90.5
Fabric reinforce hose and wire braid hose
Our hose is the best hose made.
Fabric hose Working pressure: 55bar, Bursting pressure: 220bar
Wire braid hose Working pressure: 85bar, Bursting pressure: 240bar
Available with Metric or Heavy Duty ends or ends for concrete pump or shotcrete pump and available with one or two ends. Our hoses ends are heat treated and externally swaged for long life.
We may also produce according to your requirements, please feel free to contact us
1.Schwing Rubber Hose
2.Putzmeister Rubber Hose Add to Basket
