HOT PRODUCT Rubber Concrete Pump Hose CZIC GROUP
PM DN125*3m concrete pump Fabric hose used in concrete pumps
1. It has 2~6 plies of steel wires which ensure its working pressure and workload. The ply of steel wire can be customized according to customer requirements.
2. It adds the antioxidant which extends the working time.
3. The length is 2-6m or according customers requirement.
4. It has DN125mm, DN150mm, DN175mm and other sizes or according customers requirement.
5. It is used for conveying concrete in construction work. Its working ability is 20000-30000 CBM.
6. OEM is available from us.
Steel hose
Spec.
Inner diameter (mm)
Wall thickness tolerance (mm)
Outer diameter (mm)
Working pressure (bar)
Bursting pressure(bar)
Bend radius (mm)
Weight(kg/m)
2"
50
90.75
681.5
85
240
200
2.6
2.5"
64
100.75
851.5
85
240
250
4.3
3"
76.2
12.91
1021.5
85
240
270
6.1
3.5"
89
13.51
1161.5
85
240
290
8
4"
101.6
14.21
1301.75
85
240
300
9
4.5"
115
141
1432
85
240
320
10.2
5"
127
161
1582
85
240
360
12.5
Fabric hose
Spec.
Inner diameter (mm)
Wall thickness tolerance (mm)
Outer diameter (mm)
Working pressure (bar)
Bursting pressure(bar)
Bend radius (mm)
Weight(kg/m)
2"
510.7
11.50.7
741
55
220
200
2.80.2
2.5"
63.50.8
120.7
881
55
220
250
3.70.3
3"
761
141
1041.2
55
220
270
4.90.4
3.5"
891
151
1191.2
55
220
290
5.80.4
4"
1021
16
1351.2
55
220
300
7.40.4
4.5"
114
161
1481.5
55
220
320
8.50.5
5"
1271
161
1591.5
55
220
360
90.5
Parameter:
Material
Natural rubber/steel wire
Size
DN125mm (5inch)can do 2inch-6inch
Length
3m or according to your requiement
Reinforcement
2 or 4 layer steel wire/fabric or as request
Flange size
148/157mm
Flange
one or double
Working pressure
85-220bar
Burst Pressure
250bar
Lifetime
25,000-30,000CBM
Converying material
concrete/mud/plaster
Weight
12.8kg/m
Application:
Concrete boom pump truck/ concrete placing boom
Packing:
Naked outfit,
Packed in wooden cases,
Iron frame packing,
The pallets,
Standard seaworthy export package
Package could be customized.,all according to your requirement.
