NBR rubber VL ring seal rotary seal
NBR rubber VL ring seal
V-RING is a full rubber seal for rotary shafts. The V-Ring is normally stretched and mounted directly on the shaft, where it is positioned by the inherent tension of the rubber body. It rotates with the shaft and seals axially against a stationary counterface, at right angles to the shaft,the material can be NBR and FKM,the model is VA,VS,VL and VE
The functioning of V Rings
Through its elastic fit the V-ring clamps itself in
position by
on the shaft and rotates with the shaft. Because of
this, the static sealing between the shaft and the V-ring is ensured.
The flexible sealing lip contacts the counterface - settles
tolerances and devia-tions - herewith producing the dynamic sealing. The
functioning of an V-ring serves two purposes: a dynamic sealing
element as well as a flinger. Because of the peripheral speed,
dirt and liquids are removed and will not attach to the sealing lip.
V-ring type A
V-ring type A with bevel back serves as a pressure
less, axial rod seal with a very short mounting length, which is clamped on a
shaft. The flexible sealing lip seals a counterface at a right angle to the
shaft preventing dirt, dust and splash to enter the construction.
V-ring type S
V-ring type S with bevel
back serves as a pressureless, axial rod seal which is clamped on a shaft. The
flexible sealing lip seals a counterface at a right angle to the shaft,
preventing dirt, dust and splash to enter the construction.
V-ring type L NBR
V-ring type L with
straight back serves as a pressureless axial rod seal with a very small mounting
length, which is clamped on the shaft.
The flexible sealing lip
seals a counterface at a right angle to the shaft preventing dirt, dust and
splash to enter the construction.
V-ring type E NBR
V-ring type E with
straight back serves as a pressureless axial rod seal with a very small mounting
length, which is clamped on the shaft.
The flexible sealing lip
seals a counter face at a right angle to the shaft preventing dirt, dust and
splash to enter the construction. Thetype E is designed for heavy use or is
applied in situations where larger axial
tolerances are required. This profile is delivered for shafts from 450 to
2010 mm.
