Two Roller Rubber Calender
Two-roll rubber calendar is mainly used to Roll-extrusion for rubber-sheet. Sticking & friction rubber of fabrics.
The rolls are made of chilled alloy cast iron with bored cavities and can be heated by steam or cooled by water homogenously to meet different requirements.
The machine is consisted of bedplate, frame, rolls , motor , coupling ,speed ratio gear , adjusting spacing device , the adjusting temperature device of roll .
The bedplate is whole model, Installation convenience.
Roll are made of chilled case alloy iron, the working surface of roll is hardness and smoothly. steam and cooling water can pass through inner of the rolls so that surface temperature can be adjusted .
Roll fluctuation arrange , under roll is initiative roll , motor pass through coupling ,To make under roll driving , above roll by under roll pass though speed radio driving .
Roll bearing adopt roll bearing, high precision, long service life , Axes pathway is no abrasion .
Adjusting spacing device is consisted of one left and one right hand wheel. The bearing bases need is moved and reached nip by worm and worm wheel.
There are airproof device inboard the bearing bases. The bearing is lubricated by oil.
Model
XY-2I 160x320
XY-2I 252x720
XY-2I 360x1120
XY-2I 450x1500
XY-2I 550x1830
XY-2I 610x1730
XY-2I 810x2430
Item
Roll dia
mm
160
252
360
450
550
610
810
Roll working length
mm
320
620
1120
1500
1830
1730
2430
Roll ratio
1:1
1:1
1:1
1:1
1:1
1:1
1:1
roll linear speed
m/min
7.79
1.2-12
3-20.2
2.5-24.8
2-18.7
4-36
2-20
Adjusting nip range
mm
0-4.5
0-6
0-10
0-10
0-12
0-15
0.5-25
Min.Calendering Product thickness
mm
0.2
0.2
0.2
0.2
0.2
0.2
0.5
Calendering product width
mm
250
580
920
1250
1600
1500
2150
Motor power
kw
5.5
15
37
45
75
90
160
Overall dimensions
L
mm
2200
3950
5400
7113
7420
5987
8690
W
mm
530
770
1542
1595
1760
1860
3139
H
mm
1470
1590
1681
2446
2760
2988
4270
About weight
t
~1.2
~5
~14.5
~22
~24
~30
~62
