Container Chassis (Double-Axle / Tri-Axle)
Specifications:1) Dimensions and weight: a) Nominal dimensions (L x W x H): 12,250 x 2,440 x 1,450mm b) King pin height: 1,200mm c) King pin setting: 1,000mm from rear face of front bolster d) Max. payload: 40,000kg / 45,000kg e) Tare weight: 4,400kg±2% / 5,500kg±2%2) Running system: a) Suspension system: leaf spring or airbag suspension b) Axle: various axles like BPW, YORK and FUWA with various bearings c) Tire: various brands of bias tires or radial tires d) King pin: forged steel, 2" or 3.5", welded or bolt-in e) Landing gear: 24T, 25T 3) Chassis: a) Provides 8 or 12 retractable type twist locks b) Main beam: high-tensile steel c) Surface preparation: shot blast d) Painting: zinc-rich primer and modified urethane topcoat as customers` choices4) Brake system: a) Double line air brake system with single air tank, standard connectors onfront bolster b) Optional anti-lock brake system5) Electrical system: standard electrical equipment6) Accessories: a) Tool box (box only) b) Spare wheel holder (no spare tires and wheels)
Product Name: Container Chassis (Double-Axle / Tri-Axle)Place of Origin: ChinaSpecifications:1) Dimensions and weight:a) Nominal dimensions (L x W x H): 12,250 x 2,440 x 1,450mmb) King pin height: 1,2
Specifications:1) Overall dimensions: 7,600-9,600 x 2,498 x 3,400mm2) Body dimensions: 4,800-7,000 x 2,300 x 1,000-1,500mm3) Max. gross weight: 25,000-39,000kg4) Tare weight: 12,000-14,000kg5) Max. pa
Specifications:1) Overall dimensions: 7,670 x 2,498 x 3,400mm2) Body dimensions: 5,100 x 2,300 x 1,500mm3) Max. gross weight: 25,000kg4) Tare weight: 12,000kg5) Max. payload: 13,000kg6) Engine type: W
Specifications:1) Dimensions and weight:a) Nominal dimensions (L x W x H): 13,000 x 3,000 x 1,750mmb) King pin height: 1,300mmc) Laden height: 1,200mmd) King pin setting: 500mm from rear face of front
Specifications:1) Dimensions and weight:a) Nominal dimensions (L x W x H): 13,000 x 3,000 x 1,750mmb) King pin height: 1,300mmc) Laden height: 1,200mmd) King pin setting: 500mm from rear face of front
Specifications:1) Dimensions and weight:a) Nominal dimensions (L x W x H): 13,000 x 2,500 x 4,000mmb) Internal nominal dimensions (L x W x H): 12,895 x 2,460 x 2,550mmc) King pin height: 1,200mmd) Kin
Specifications:1) Dimensions and weight:a) Nominal dimensions (L x W x H): 13,000 x 2,500 x 4,000mmb) Internal nominal dimensions (L x W x H): 12,895 x 2,460 x 2,550mmc) King pin height: 1,200mmd) Kin
