Chainless Drive Folding Electric Bicycle
Product Name: Chainless Drive Folding Electric BicycleModel Number: XM-QAPlace of Origin: ChinaFeatures:1) Max. speed: 25-35km/h2) Range per charge: 50km3) Charging time: 5 - 6h4) Weight of whole bicycle: less than 25kg5) Loading weight: 80kg6) Climbing ability: 12-degree and 15-degree pedal assisted7) Torque: 13.5 x 4 = 54N.m8) Type of battery: lithium battery (36V and 12Ah)9) Colors: red, yellow, blue, Chinese date red, black and customized10) Traveling noise: less than 62dB11) Light of the bikea) Head light: integration of horn, battery gauge and the head light of the bikeb) Rear light: when we use rear brake, the rear light will be on12) Voltage: 220V (110V) and 50Hz13) Power: 250W14) Charging way: direct15) Battery capacity: 900 times16) Burglarproof system: front fork lock and wireless alarm lock17) Safety equipment: electricity supply will be off when brake18) Braking system: front-wheel "V" brake and rear-wheel disc brake19) Suspension: front shock absorber20) Motor:a) Brushless, inner rotor, direct current and high speedb) Characterized in weak current (36V 250W)c) Power factor: 84%d) Mechanical efficiency: 95%e) Starts quickly and drives stablyf) Patent design of shift system and clutch ensures weak current and strong torquewhich enhance climbing capacity21) Frame: made of steel and acrylic painting22) Drive system:a)Patent designed chainless drive system and clutch eliminate the Bottleneck withdrive system of conventional electric bicycle.b)Bottleneck with drive system of conventional electric bicycle:when the users pushthe bike or ride the bike by pedal,the users will feel difficult and tired goaheadc)Chainless drive system and clutch eliminate the bottleneck, that is:i)When electric power,the clutch will be separated from man force device automatically,ii)And instead,when manpower,clutch will be separated from electricity device accordingly.iv)So when manpower,motor will be will be off-power all the time and the bike canbe pedaled as easy as a Normal bike.v)If there is no electricity supply to the motor,the motor will be off all the time,soit will be easy to push it as a Normal bike.Revolutionary E-bike, ideal for your way23) Driven systema) Hub motorb) Driven by rear wheel24) Folding dimensions: 75 x 36 x 72cmOuter packing:7-layer carton dimensions: 75 x 36 x 72cmConveyance:Qty/20` FCL: 144pcsQty/20` FCL: 297pcsQty/40` HQ: 397pcs
