Producer information
Company: Ceda Industries Ltd. |
|
Address: Congling Industrial Zone, Yaocunwu, Duran Town, Jiangmen, Guangdong, China (Mainland) Zip: 529000 |
|
Phone: +86-750-3660611 +3660612 |
|
DVB-T
Tuner and channel:1) Input terminal: 75 ohms2) Receiving frequency: 48.25 ~ 863.25MHz tuning range3) Carrier type: 2K or 8K4) Code rate: 1/2, 2/3, 3/4, 5/6 or 7/85) Guard interval: 1/4, 1/8, 1/16 or 1/326) Channel bandwidth: 6MHz, 7MHz, 8MHz7) Modulation: QPSK, 16QAM or 64QAMMPEG transport stream A/V decoding:1) Transport stream: MPEG-2 ISO/IEC 138182) Transport stream specification3) Profile and level: MPEG-2 MP at ML4) Input T/S data rate: 80Mbps max.5) Aspect ratio: 4:3 (full, center, letter box), 16:96) Video resolution: 720 x 576 (PAL), 720 x 480 (NTSC)7) Audio decoding: MPEG-1 audio layer 1 & 2, musicam8) Audio mode: stereo, dual channel, joint stereo, mono9) Sampling rate: 32, 44.1 and 48kHzCPU and memory:1) Processor: Lsi97002) Flash memory: up to 4MB (default 2MB)3) Program DRAM: 8MB4) EEPROM: 2KBA/V and data in/out (optional):1) SCART: TV x 1, VCR x 12) RGB video out: TV SCART x 13) CVBS video out: RCA x 1, SCART x 2 (TV, VCR)4) S/PDIF: RCA x 15) Data interface: RS232C, baud rate 9600 ~ 115200, 9 pin D-SubPower supply:1) Input voltage: AC 95V~240V, 50/60Hz2) Power consumption: 20W max.
