Home multi-media distribution box is the center of whole home cabling system, corresponding to management center of telephone, computer, TV and video set. It is consist of voice module, data module, video module and power module. Extension slots are easily for future use. Several computers can be on the Internet at one time. Several TVs can be watched in different rooms. We can talk with each other by extension telephones at home.Home multi-media distribution box 05AExternal dimension: 278 x 194 x 138mmInstallation dimension: 264 x 180mm (hard-drawn steel)Characteristic:1) Mounting plate can be turned over; three modules mounted; easily expanded2) Back wiring and front panel operation3) 2 inlet 8 outlet CATV or satellite TV4) Slipping lock structure, flexible and easy erectionHome multi-media distribution box 05BExternal dimension: 278 x 194 x 106mmInstallation dimension: 264 x 180 x 88mm (ABS)Characteristic:1) Mounting plate can be turned over; three modules mounted; easily expanded2) Back wiring and front panel operation3) 2 inlet 8 outlet CATV or satellite TV4) Slipping lock structure, flexible and easy erectionHome multi-media distribution box 05CExternal dimension: 278 x 194 x 106mmInstallation dimension: 264 x 180 x 88mm (hard-drawn steel)Characteristic:1) Mounting plate can be turned over; three modules mounted; easily expanded2) Front panel operation, remarkable shape3) Slipping lock structure, flexible and easy erection4) 5-1000MHz CATV bidirectional distributor for digital TVPJ0904003 Home multi-media distribution boxExternal dimension: 299 x 284 x 138mmInstallation dimension: 269 x 256 x 120mmCharacteristic:1) Mounting plate can be turned over easily and flexibly2) Back wiring and front panel operation3) Panel material is ABS and box material is Zinc-plating hard-drawn steel4) Wiring space margin for more module installations5) Function: 6 module slots for any module erection; CATV distributor at the bottomPJ0904006 Home multi-media distribution boxExternal dimension: 600 x 494 x 140mmInstallation dimension: 580 x 450 x 120mm (wall-embedded)Characteristic:1) Better steel plate, remarkable shape2) Inner turnover structure, maximum 9 module mounted3) With power plugs and one switch set for 2-8 routes or 4-16 routes4) With one 8-route network switch set5) Good ventilation performance, keeping the system stableThis type of home multi-media distribution box with turnover structure and module structure consists of bottom box, turnover plate and front panel. There are 9 module slots on the turnover plate. One 8-route network swatch set or ADSL device or fiber interconnection box can be mounted in the box. One CATV amplifier (1 in 4 out or 1 in 6 out or 1 in 8 out) can be mounted in the bottom box. One 2-in 8-out or 4-in 16-out telephone switch set also can be mounted in the box. A ventilating fan mounted in the box.
Usage1) Suitable for the connection and wiring between the main cable and the branch cable of cities, countryside and enterprises2) The module can be overturned resulting in easy operation and mainten
Features:1) Various information modules provide multiple choices for wiring system2) Units with colors easy to identify and easy to manage network3) Be able to meet the location requirement of various
