2-Way Power Splitter (JCSP-1202) (2-Way Power Splitter (JCSP 202))

Zoom in

Producer information

Company:
Hangzhou Jointcom Communication Technology L.T Company

Address:
1 Load Nanshan Road, Qiandaohu Town, Chun'an County, Hangzhou, Zhejiang, China (Mainland) Zip: 310012

Phone:
+86-571-88918999-815

2-Way Power Splitter (JCSP-1202)

Specifications:1) Frequency range (MHz): 800 - 2,5002) Split loss (dB): 3.013) Insertion loss (dB): ≤3.264) Ripple in-band (dB): ≤±0.25) Return loss (dB): ≥206) Amplitude balance (dB): ≤0.27) Phase balance (°): ≤58) Impedance (Ω): 509) PIM (dBc): ≤-140@+43dBm x 210) Connector: N-F11) Power rating (W): 30012) Temperature (Ω): -30 ~ +7013) Size (mm): 216 x 68 x 1614) Weight (kg): 0.27

Add to Basket

Web address

Other goods of this manufacturer :

2-Way Power Splitter (JCSP-1202)
	Product Name: 2-Way Power Splitter (JCSP-1202)Place of Origin: ChinaSpecifications:1) Frequency range (MHz): 800 - 2,5002) Split loss (dB): 3.013) Insertion loss (dB): ≤3.264) Ripple in-band (dB):

3-Way Power Splitter (JCSP-1204D)
	Specifications:1) Frequency range (MHz): 800 - 2,5002) Split loss (dB): 6.023) Insertion loss (dB): ≤6.324) Ripple in-band (dB): ≤±0.25) Return loss (dB): ≥206) Amplitude balance(dB):

4-Way Power Splitter (JCSP-1204D)
	Product Name: 4-Way Power Splitter (JCSP-1204D)Place of Origin: ChinaSpecifications:1) Frequency range (MHz): 800 - 2,5002) Split loss (dB): 6.023) Insertion loss (dB): ≤6.324) Ripple in-band (d

Filter
	Specifications:1) Frequency range (MHz): 870 - 8802) Band width (MHz): 103) Insertion loss (dB): ≤1.64) Ripple in band (dB): ≤1.05) Return loss (dB): ≥186) Stopband attenuation (dB):

Filter
	Product Name: FilterPlace of Origin: ChinaSpecifications:1) Frequency range (MHz): 870 - 8802) Band width (MHz): 103) Insertion loss (dB): ≤1.64) Ripple in band (dB): ≤1.05) Return loss (d

Filter (JCDLX-800-10-07ST2)
	Specifications: (RX Channel, TX Channel)1) Frequency range (MHz): 825 - 835, 870 - 8802) Band width (MHz): 10, 103) Insertion loss (dB): ≤2.1, ≤2.14) Ripple in band (dB): ≤0.8, ≤0.85) Stop

Filter (JCDLX-800-10-07ST2)
	Product Name: Filter (JCDLX-800-10-07ST2)Place of Origin: ChinaSpecifications: (RX Channel, TX Channel)1) Frequency range (MHz): 825 - 835, 870 - 8802) Band width (MHz): 10, 103) Insertion loss (dB):
