Features:1) Product: TC-8000 electronic controller2) Characteristics:a) Inside or long distance resistor variable temperature sensitive element (NTC)b) The output can be changed over: direct (DA) or reversible (RA) by theinside jumper or long distance centralized switch or SPST if neededc) Adjustable proportional bandd) Spare set pointe) Flexible installation: wall-mounted, embedded in plate, concealed in the fancoil in the terminal unit.3) Technical data:a) Set-point range: -40~140oCb) Medium: water, oil and other liquidc) Pressure: 1.0MPad) Power consumption: 36/50VAe) Power supply: 220V AC/24V AC, 50/60Hzf ) Output signal: 24V AC (0.5A) by bi-directional silicone controlled recifierg) Shell: fireproof ABS plastich) Integral time: 5 or 2.5 minutes(set by the internal jumper)i) Wiring connection: terminal connection max 1.5 square seti-meter wire4) Applications: used in central air condition, heating and cooling systems. Itmakes set with TSC series temperature sensor and output increasing signalin proportional and integral control arithmetic way to adjust reversiblemotor actuator so as to control the temperature
Features:1) Product: TC-8000 electronic controller2) Characteristics:a) Inside or long distance resistor variable temperature sensitive element (NTC)b) The output can be changed over: direct (DA) or r
Features:1) Product: ECK series thermostatic radiator valve2) A kind of proportional modulating controller3) Avoids over heating and reduce the heating cost5) Technical data:a) Adjusting temperature:
Features:1) Product: ECK series thermostatic radiator valve2) A kind of proportional modulating controller3) Avoids over heating and reduce the heating cost5) Technical data:a) Adjusting temperature:
Features:1) Product: ECK series thermostatic radiator valve2) A kind of proportional modulating controller3) Controls the heat water flow to the room and keeps the room withcomfortable temperature4) A
Features:1) Technical data:a) Power supply: 24VAC, 220VACb) Ambient temperature: -10~60oCc) Relative humidity: &le95%RHd) Inserted temperature Sensor, and remote NTC signale) P, I parameters are adjus
Features:1) Technical data:a) Power supply: 24VAC, 220VACb) Ambient temperature: -10~60oCc) Relative humidity: &le95%RHd) Inserted temperature Sensor, and remote NTC signale) P, I parameters are adjus
