Specifications:1) Output range: from 30kW (37.5kVA) up to 150kW (187.5kVA)2) Engine model: R3105D1, R4100D1, R4100ZD1, R4105D1, R4105ZD1, R6105ZD1, R6105ZLD3) Alternator model: GM/MP/TFS4) Water-cooled5) Key start / auto start, low noise6) Control system:a) Automatic alarm system: the unit has the acoustic-optics alarmsystem and arrestor for any situation as the start defeat; The wateris over temperature; The oil pulls down, over speed, over load andover currentb) Operation display:i) Unit voltage, tri-phase load current and frequency displayii) Water temperature, oil pressure displayiii) Fuel level, fuel temperature displayiv) Audible and visual alarm lamps and buzzersStandard configuration:1) Engine model: R4105ZD12) Alternator model: TFS-503) Rated output: 50kW (62.5kVA)4) Closed cooling5) Fuel consumption: 210g/kWh6) Prepare output: 132kW (165kVA)7) Rated voltage: 230 / 400V8) Rated current: 90.2A9) Power factor: 0.8 lagging10) Connection type: 3-phase, 4-wire11) Rated frequency: 50 / 60Hz12) Excitation way: brush or brushless13) Rotating speed: 1,500/1,800rpm14) Overall dimensions: 2,100 x 900 x 1,600mm15) Weight: 1,100kg16) Accessories: exhaust elbow, bellow, muffler17) Supply standard collocation:a) Diesel engine with all accessories, 3 filters and electric systemsb) Alternatorc) Steel structured) Fan and water tank cooling systeme) Flange connectorf) 12 / 24V starting motor and charge engineg) Air cleaner, fuel cleaner, oil cleanerh) On-board control paneli) MCCB air conservation switchj) 12 / 24V starting accumulator and battery linek) Set shock absorberl) High-efficient silencerPacking:Wooden case
