Diesel Generator Set 500KVA (400KW)
Features1) Universal design and manufacture2) Most wildly used around the world3) With most service terminals4) Engineers are familiar with Cummins powered gensets5) You can find spare-parts very easyShunhengxin`s Guarantee for SHX Series Generators1) Guarantee Peried: One year or 1000hours whichever comes first.2) During the guarantee peried, the spare-parts will be sent through your shipping agency in China.3) Spare-parts can also be sent throught FEDEX or DHL, but the shipping cost will be charged on both sides for 50%.4) 24 hours service hotline is alvailable for customers.Power Specifications1) 1500RPM at 50Hz/1800RPM at 60Hz2) Water Cooled3) TurbochargedElectrical Specifications1) Power Factor: 0.8 Lagging2) 3 Phase 4 Pole3) Insulation: Class H4) Brushless5) Self-Exited6) IP22 Protection7) AVR regulation8) Starting by BatteryVoltage1) Frequency at 50Hz: Available in 400/230Volts, 415/240Volts, 380/220Volts, 220/127Volts, and 200/115Volts.2) Frequency at 60Hz: Available in 480/227Volts, 440/254Volts, 220/117Volts, and 208/120Volts.Models (50Hz): SCE560Prime Power: 500(KVA)Standby Power: 560(KVA)Fuel Consumption: 219(g/KW.h)Lube Consumption: 0.50% of fuel consumptionEngine Model: KTA19-G4Cylinders: 6LDisplacement: 18.9(L)Compression Ratio: 13.9:1Bore*Stroke: 159*159(mm)Starting: ElectricCooling: WaterAlternator Model: EG315L-400NSpeed Governor: ElectricalLength 3450 (mm)Width 1325 (mm)Height 1968 (mm)Weight 4672(kg)Special Type Generator Set1) Acoustic Generator Set2) Containerized Generator Set3) Trailer-Mounted Generator Set4) Mobile Generator Set (Truck Mounted)China Shunhengxin Diesel Gensets Co., Ltd. Is a professional diesel generator setsmanufacturer, produces Cummins, Perkins, Deutz, Man, Daewoo engine powered generatorsets. Both open sets and sound attenuated gensets, container and trailer generator sets are also available.Cummins engines are produced in China by two Cummins Joint-Venture Companies: DongfengCummins (B,C&L Series) and Chongqing Cummins (M,N&K Series), which are usingCummins` most advance technology with globally uniform quality standard but remainthe manufacturing cost in a much low level, Shunhengxin and CUMMINS guaranteethe most convenience and shortcut service through their service networks countrywide and worldwide.
