Link Fitting & Strain Clamp

Aluminum-alloy Dead End ClampType: NXJ-1, NXJ-2, NXJ-3, NXJ-4Wire range: JKLYJ-35, JKLYJ-50, JKLYJ-70, JKLYJ-95Ultimate strength: 5.8KN, 12.0KNBall EyeType: QP-7, QP-10, QP-16, QP-20, QP-30Wire range: X-4.5, X-10, X-16, X-20, X-30Ultimate strength: 69KN, 100KN, 160KN, 200KN, 300KNSocket EyeType: W-7A, W-7BWire range: X-7, X-4.5Ultimate strength: 70KNU ShackleType: U-7, U-10, U-12, U-16Ultimate strength: 70KN, 100KN, 120KN, 160KNZ Right Angle Hung PlateType: Z-7, Z-10, Z-12, Z-16, Z-20Ultimate strength: 70KN, 100KN, 120KN, 160KN, 200KNBolt Type Tension ClampType: NLL-1, NLL-2, NLL-2, NLL-3,Diameter of conductor: 5.0~10.0, 10.1~14.0, 14.1~18.0, 18.1~23.0Number of bolt: 2, 3, 4, 5Diameter of bolt: 12mm, 16mmUltimate strength: 18KN, 41KN, 71KN, 91KN

Add to Basket

Web address

Other goods of this manufacturer :

Outdoor High-Voltage Isolating Switch
	Use conditions:1) The altitude above sea level does not surpass 3,000m2) Surrounding air temperature:a) Upper limit: +40°Cb) Lower limit general area: -30°Cc) High and cold area: -40°C3

Outdoor High-Voltage Isolating Switch
	Use conditions:1) The altitude above sea level does not surpass 3,000m2) Surrounding air temperature:a) Upper limit: +40°Cb) Lower limit general area: -30°Cc) High and cold area: -40°C3

Outdoor Vacuum Circuit Breaker
	Product Name: Outdoor Vacuum Circuit BreakerModel Number: ZW32-12Place of Origin: ChinaFeatures:1) ZW32-12 series pillar type outdoor vacuum breaker is a kind of outdoor high voltageswitch equipment w

Outdoor Vacuum Circuit Breaker
	Features:1) ZW8-12, ZW8-12G series high-voltage vacuum circuit breaker is a kind of outdoor high-voltage switch equipment with 50Hz three-phase alternating current and 12kV rated voltage2) It is mainl

Composite Cross-Arm & Post Insulator
	Features:1) Manufactured by means of injection whole-molding technology2) The juncture between end fitting and core is totally embedded in HTV silicone rubber, eliminating conventional and traditional

Composite Cross-Arm & Post Insulator
	Features:1) Manufactured by means of injection whole-molding technology2) The juncture between end fitting and core is totally embedded in HTV silicone rubber, eliminating conventional and traditional

Composite Dry Type Wall Bushing Insulator
	Features:1) Manufactured by means of injection whole-molding technology2) The juncture between end fitting and core is totally embedded in HTV silicone rubber, eliminating conventional and traditional

Composite Dry Type Wall Bushing Insulator
	Features:1) Manufactured by means of injection whole-molding technology2) The juncture between end fitting and core is totally embedded in HTV silicone rubber, eliminating conventional and traditional

Composite Insulator
	1) Composite post Insulator GW9-10KV2) Composite Post Insulator RW5-35KV3) Drop-out Fuse Insulator RWL-10KV4) Railway Composite Post Insulator FZST-27KV
