Non-pressure Solar Water Heater

Evacuated glass solar collectors are directly plugged into storage tanks and suchsystems occupy less space. Water directly circulates inside the evacuated glasstubes and such systems gain the highest efficiency.Features:1) Highest efficiency2) Simple configuration3) It is the most reliable and economic system when manual controls areacceptable4) Automatic controllers (CPU based) can be applied to these systems5) Mechanical level control auto tank (felting ball based) is optional6) Electrical heating element is optional7) Sacrificing anode is optional8) Vacuum tube style: AL/N/ALSpecifications:1) Vacuum tube counts: 15, 18, 20, 24, 302) Angle: 42oC3) Aperture area: 2.10-4.23m24) Theory volume: 150-310L5) Tube size: Φ47 x 1,650mmMaterial:1) Inner tank: SUS304-2B stainless steel2) Outer tank: aluminum-zinc coated steel or color steel3) Frame: Galvanized steel4) Isolation material: polyurethane
