Bluetooth Stereo Module (BC-03)

Bluetooth Stereo Module (Model: BTM-30)CSR BC3 class 2DESCRIPTION:BT-M30 is certified by V1.2. It BT-M30 is a fully integrated Bluetooth Class 2 module using CSR BlueCore3-Multimedia External solution which include Radio Frequency, Baseband DSP, Link Manager, and Host Control Interface. Its sufficient pin definitions, high receiving sensitivity, low power consumption, and low cost, BT-M30 is suitable for need low power consumption devices.FEATURE:1. Bluetooth Specification V1.22. Support up to 7 ACL connections and 3 SCO connection3. Support Faster connection, Flush timeout, Synchronization, LMP improvements, AFH, Parameter ranges and LMP SCO Handle.4. Up to 12 PIO/ 3 AIO pin definitions is ideally suited for rapid embedded development any kind of products.5. 13 or 16bit linear, 8bit PCM interface6. UART interface with programmable baud rate7. Compact size (25.25x15.25x 2.0 mm ) can be fit any type of product8. RF output power -5dBm ~ +3 dBm (class 2).9. Output interface over USB/UART/PCM/SPI.APPLICATIONS:1. Stereo Headphones,2. Automotive Hands-Free Kits,3. Echo Cancellation,4. Enhanced Audio Applications,5. A/V Profile support.SPECIFICATION:1. Supply Voltage: VDD: 3.3V+/-0.1V Regulated supply voltage2. Carrier Frequency: 2400MHz to 2483.5MHz( USA , Spain ,France)3. Modulation Method: GFSK,1Mbps, 0.5 BT Gaussian4. Maximum Data Rate: Asynchronous:723.2kbps/57.6kbps5. Synchronous: 433.9kbps/433.9kbps6. Transmission Power: +3dBm to -20dBm; Power control 6 stage7. Hopping: 1600hops/sec, 1MHz channel space8. Receiving Signal Range: -83dBm to -20 dBm9. Receiver IF Frequency: NEAR ZERO frequency10. Baseband Crystal OSC: 16MHz11. Output Interface: USB,PCM,SPI,UART12. Operation Temperature: -20 to +70 degree13. Storage Temperature: -30 to +90 degree14. Absolute Max Supply Voltage: 3.6V for VDD,other VDD +0.3V15. Bluetooth Specification: Ver1.216. USB Specification: Ver 1.1 and Ver 2.0Remark: All contents are subject to change without notice.

Add to Basket
