Electrical Discharge Machine
Precision EDM forming machine is suitable for producing and processing of precision mould and machine parts of household electric appliance, packing container, electronic components, office goods and so on.Three features:1.High comprehensive index, the best wavy power supply.2.Good human-machine interface, easy operation.3.Three-axes link servo control, multi-type program processing.Technical parameter of precision EDM forming machineItem SIZE MODELD7125 D7135 D7145 D7155X axes (left-right) strole (servo drive) mm 350 450 550 650Y axes (front-back) strole (servo drive) mm 250 350 450 550Z axes stroke Servo stroke mm 180 200 250 300Asistant stroke mm 200 220 280 330Working table dimension mm 700×350 720×400 800×500 1000×550Working oil tank dimension (L×W×H)mm 700×351×350 1080×640×380 1200×790×480 1510×1000×560Distance of electrode head to working table mm 20~400 20~440 20~550 100~650Max. electrode allowed load Kg 25 50 75 100Max. working table load Kg 400 800 1000 1200Oil box cubage L 300 370 500 800Filter system filter is changeableMax. processing current A 30 50 80 100Max. processing speed mm 3 /min 280 360 630 750Min. electrode consumption rate % 0.05 0.05 0.05 0.05Lowest surface roughness"u"m Large area is 0.4 small area is 0.2Max. consumption power output Kw 5 7 8 10Exterior dimension mm 1400×1150×2000 1400×1270×2120 1600×1700×2350 1950×2000×2450Machine weight Kg 1200 1700 2000 2200*The company is subject to change without further notice.
Description: the injection machine is high performance/price rate machine with precision, stable and long life features. The injection forming covers computer parts, precision plugs, transparent, inje
The application of our motors are medical, floor care, pump, tool, automobile, households etc.The motor diameter is 1.5~4.0 inches and the voltage is in the wide range of 12V~240V, with 2KW maximum. W
Application:Synchro Motor PM ,PM Stepping Motor Dc,Brushless DCMotor, Laser Fax Machine,Electrostatic Duplicator,Magnetic Sensor,Speaker,Buzzer,Contactless Allot Meter
The application of our motors are medical, floor care, pump, tool, automobile, households etc.The motor diameter is 1.5~4.0 inches and the voltage is in the wide range of 12v~240v, with 2kw maximum.
We can do all kinds of magnetic products. Arc, ring, block, disc, segments...Grade:IsotropicDry-Aniso.Wet-Aniso.Application:Micro-motor,Toy,Stationary,Holder,Household Appliance,OA Facilities,Electric
We can produce all kinds of bar rubber magnets for micro-motor as your request.Rubber MagnetsIsoTropic rubber magneTs:JPM-R1A Br175-195mT 1750-1950Gs (BH) max. 6-7.6kj/m3JPM-R1B Br170-190mT 1700-1900G
