Notice:1) Do not use winch as a hoist, do not use for transportation of people2) Don`t operate and spool under full load over one minute continuously3) While the motor is overheating, please stop for a while to cool down4) Limited lifetime warrantySpecifications:1) Rated line pull: 10,000lbs (45.4kN)2) Motor: series wound, 2.7kW/3.6HP (12V), 3kW/4.0HP (24V)3) Gear reduction ratio: 294:1 (12V), 210:1 (24V)4) Cable (dia. x L): Φ3/8" x 85` (Φ9.2mm x 26m)5) Drum size (dia. x L): Φ2.48 x 9" (Φ63 x 228mm)6) Overall dimensions (L x W x H): 22.4 x 7.1 x 10.63" (570 x 180 x 270mm)7) Mounting bolt pattern: 10 x 4.5" (254 x 114.3mm)8) Weight: 84.2lbs (38.2kg)
Notice:1) Do not use winch as a hoist, do not use for transportation ofpeople2) Don`t operate and spool under full load over one minutecontinuously3) While motor is over heating, please stop for a whi
Note:1) Do not use winch as a hoist, do not use for transportation ofpeople2) Limited lifetime warrantySpecifications:1) Rated line pull: 10,000lbs (4,536kg)2) Motor displacement: 50ml/rpm3) Gear redu
Notice:1) Do not use winch as a hoist, do not use for transportation of people2) Don`t operate and spool under full load over one minute continuously3) While motor is over heating, please stop for a w
Notice:1) Do not use winch as a hoist or to transport people2) Don`t operate and spool continuously under full load for over oneminute3) During motor overheat, stop and allow to cool4) Limited lifetim
Features:1) Free spooling clutch2) Automatic braking action3) Specially designed differential rack wheel gearing for heavy duty4) Great gear ratio designed for steering power drive available5) Special
Notice:1) Do not use winch as a hoist, do not use for transportation ofpeople2) Don`t operate and spool under full load over one minutecontinuously3) While motor is over heating, please stop for a whi
Features:1) Free spooling clutch2) Automatic braking action3) Specially designed differential rack wheel gearing for heavy duty4) Great gear ratio designed for steering power drive available5) Special
Notice:1) Do not use winch as a hoist, do not use for transportation of people2) Don`t operate and spool under full load over one minute continuously3) While motor is over heating, please stop for a w
