Y5w-24 Surge Arrester
|
|
Rated voltage: 24kvMcov: 20kvArrester nominal current: 5ka / 10kaMax. Residual voltage at 8 / 20 micro sec thunder shock: 70kv2ms square wave current withstand: 150a / 250a4 / 10 micro sec current sho
|
| |
|
52-1 52-2 Insulation Materials
|
|
Suspension insulator:52-1: D (165mm) H (141mm) leakage distance (178mm)52-2: D (197mm) H (146mm) leakage distance (210mm)
|
| |
|
52-3 52-5 Porcelain Insulator
|
|
Suspension insulator:52-3: D (254mm) H (146mm) leakage distance (305mm)52-5: D (254mm) H (146mm) leakage distance (279mm)
|
|
|
|
Disc Suspension Insulator
|
|
|
Suspension insulator:52-1: D (165mm) H (141mm) leakage distance (178mm)52-2: D (197mm) H (146mm) leakage distance (210mm)
|
| |
|
Insulation Materials
|
|
Rated voltage (kv) : 35KVRated curve withstand loading: 70KN / 100KNFrame height: 650mmMax. Diameter of insulator: 148 / 118mmMin. Electric arc distance: 485mmMin. Creepage distance: 1280mm
|
| |
|
|
|
POST Type Insulator
|
|
|
Rated voltage (kv) : 110KVRated curve withstand loading: 70KN / 100KNFrame height: 1240mmMax. Diameter of insulator: 148 / 118mmMin. Electric arc distance: 1060mmMin. Creepage distance: 3180mm
|
| |
|
Wall Switches
|
|
We supply 12KV-35KV outdoor and indoor disconnector switch.
|
| |
|
24kv Suspension Insulator
|
|
|
Rated voltage (kv) : 24KVRated curve withstand loading: 70KN / 100KNFrame height: 450mmMax. Diameter of insulator: 148 / 118mmMin. Electric arc distance: 235mmMin. Creepage distance: 635mm
|
|
